| CHAIN TYPE |
CODE. NO |
MATERIAL | PLATE WIDTH (K) |
WORK- ING LOAD (MAX) |
BACK- FLEX RADIUS (MIN) |
WEI- GHT |
|||
|---|---|---|---|---|---|---|---|---|---|
| PLATE | PIN | ROLLER CHAIN |
MM | INCH | N | R | kg/M | ||
| TS550P TS635P TS762P TS826P TS101.6P TS1143P TS1524P TS1905P |
1163 1164 1165 1166 1166-1 1167 1168 1169 |
STAINLESS STEEL |
STEEL | 55.0 63.5 76.2 82.6 101.6 114.3 152.4 190.5 |
2.16 2.50 3.00 3.25 4.00 4.50 6.00 7.50 |
4950 | 130 | 2.5 2.7 3.0 3.2 3.7 4.0 4.9 5.8 |
|
