| CHAIN TYPE |
CODE. NO |
MATERIAL | PLATE WIDTH (K) |
WORK- ING LOAD (MAX) |
SIDE- FLEX RADIUS (MIN) |
BACK- FLEX RADIUS (MIN) |
WEI- GHT |
||
|---|---|---|---|---|---|---|---|---|---|
| PLATE | PIN | MM | INCH | N | R | R | kg/M | ||
| PR1700 | 5513 | ACETAL | STAIN- LESS STEEL |
55 | 2.17 | 2670 | 150 | 38 | 1.26 |
