| CHAIN TYPE |
CODE. NO |
MATERIAL | PLATE WIDTH (K) |
WORK- ING LOAD (MAX) |
SIDE- FLEX RADIUS (MIN) |
BACK- FLEX RADIUS (MIN) |
WEI- GHT |
||
|---|---|---|---|---|---|---|---|---|---|
| PLATE | PIN | MM | INCH | N | R | MM | kg/M | ||
| LBP 953 CHT |
1241 | ACETAL | STAIN- LESS STEEL |
95.3 | 3.75 | 3830 | 667 | 400 | 3.30 |
| CHAIN TYPE |
CODE. NO |
MATERIAL | PLATE WIDTH (K) |
WORK- ING LOAD (MAX) |
SIDE- FLEX RADIUS (MIN) |
BACK- FLEX RADIUS (MIN) |
WEI- GHT |
||
|---|---|---|---|---|---|---|---|---|---|
| PLATE | BASE CHAIN |
MM | INCH | N | R | MM | kg/M | ||
| LBP1905CHT LBP2540CHT LBP3048CHT |
1242 1243 1244 |
ACETAL | STAIN- LESS STEEL |
190.5 254.0 304.8 |
7.50 10.00 12.00 |
3830 | 610 610 680 |
400 | 4.50 5.71 6.38 |
