| CHAIN TYPE |
CODE .NO |
MATE- RIAL |
PLATE WIDTH (K) |
WORK- ING LOAD (MAX) |
SIDE- FLEX RADIUS (MIN) |
BACK- FLEX RADIUS (MIN) |
WEI- GHT |
||
|---|---|---|---|---|---|---|---|---|---|
| PLATE | PIN | MM | INCH | N | R | R | kg/M | ||
| SS826CT SS1143CT SS1905CT |
1255 1256 1257 |
STAINLESS STEEL |
82.6 114.3 190.5 |
3.25 4.50 7.50 |
4950 4950 4950 |
457 610 610 |
70 70 70 |
3.10 3.80 5.50 |
|
