CHAIN
TYPE |
CODE.NO |
MATERIAL |
PLATE
WIDTH(K) |
WORKING
LOAD(MAX) |
BACKFLEX
RADIUS(MIN) |
WEIGHT |
PLATE |
PIN |
ROLLER
CHAIN |
MM |
INCH |
N |
R |
kg/M |
TS550P
TS635P
TS762P
TS826P
TS101.6P
TS1143P
TS1524P
TS1905P |
1163
1164
1165
1166
1166-1
1167
1168
1169 |
STAINLESS
STEEL |
STEEL |
55.0
63.5
76.2
82.6
101.6
114.3
152.4
190.5 |
2.16
2.50
3.00
3.25
4.00
4.50
6.00
7.50 |
4950 |
130
|
2.5
2.7
3.0
3.2
3.7
4.0
4.9
5.8 |
